U type Ground screw with U885/101/68/M12

YPQB-2674

Hot-dip galvanised ground screw with a U-profile bracket designed for timber and steel framework foundations, including terraces, garden beds, greenhouses, fencing, and lightweight outbuildings. Featuring a 68 mm diameter, 865 mm height, and a maximum load capacity of 580 kg. The integrated U-bracket with side fixing holes and M12 threaded mount facilitates exact height alignment and straightforward manual installation using a lever without specialised machinery.

More details

earth screw, ground screw, screw pile, galvanised ground screw, ground anchor, decking foundation, fence post screw, U-profile ground screw

11,47 € tax incl.

Ask about product
U type Ground screw with U885/101/68/M12

U type Ground screw with U885/101/68/M12

Hot-dip galvanised ground screw with a U-profile bracket designed for timber and steel framework foundations, including terraces, garden beds, greenhouses, fencing, and lightweight outbuildings. Featuring a 68 mm diameter, 865 mm height, and a maximum load capacity of 580 kg. The integrated U-bracket with side fixing holes and M12 threaded mount facilitates exact height alignment and straightforward manual installation using a lever without specialised machinery.



More info

Ground screw for decking and timber frame structures

This hot-dip galvanised ground screw with a U-profile bracket provides a durable foundation without concrete works. It is engineered for terraces, raised garden beds, greenhouses, aviaries, fencing, and lightweight support frameworks.

Framework mounting and adjustment

The integrated U-bracket accommodates timber joists and metal beams. Pre-drilled side holes allow secure fastening at the required elevation. A dedicated M12 threaded mount at the base of the bracket enables precise millimetre-level height alignment or the attachment of bespoke structural connectors.

Manual installation

The open U-bracket allows straightforward installation without requiring heavy machinery. Inserting a solid steel bar or timber batten between the bracket flanges creates leverage to manually drive the screw clockwise into the ground.

Technical specifications

Model U885/101/68/M12
Material Galvanised steel
Profile type U
Total height 865 mm
Height above ground Up to 180 mm
Diameter 68 mm
Wall thickness 1.8 mm
Load capacity 580 kg
Weight 3.2 kg
