RESPO 1000V541T209 Braked Boat Trailer 1000kg

Respo 1000V541T209 Braked Boat Trailer

The Respo 1000V541T209 is a robust and reliable boat trailer designed specifically for rotationally moulded boats. Identical in design to the 750V511T209 model, this version is equipped with a braking system, offering enhanced safety and stability for heavier loads. It is officially approved by Pioner Boat AS and is perfectly suited for Pioner 13, Pioner 14, and Pioner 15 Allround models, as well as River 420 and 460 boats.

Constructed with a hot-dip galvanised frame, this trailer is built to withstand harsh marine environments and resist corrosion. It features a rear tilting frame and a comprehensive set of rollers to ensure easy loading and unloading of your vessel. With a gross weight of 1000 kg and a substantial payload capacity of 737 kg, it is an ideal choice for boat owners seeking durability and performance.

Key Features

• Durable Construction: Hot-dip galvanised frame ensures long-lasting protection against rust and corrosion.
• Braking System: Equipped with brakes for increased safety during transport and higher load capacity.
• Waterproof Lighting: Features waterproof front LED lights, LED rear marker lights, and foldable rear lights to protect the electrical system during launching.
• Easy Loading: Includes a rear tilting frame, two roller bunks, and five keel rollers (one adjustable) to support the hull and facilitate smooth launching.
• User-Friendly Design: Comes with a walkway for safe access, full metal step-on mudguards, and an adjustable winch stand (vertical and horizontal).
• Complete Equipment: Includes a jockey wheel with clamp, lashing eyes for securing the load, and an 800kg winch with a 5cm x 7.5m belt.
• Hub Protection: Fitted with watertight hubs to prevent water ingress and extend bearing life.

Technical Specifications
