AFLATEK Screw75VSD Screw Type Compressor View larger

AFLATEK Screw75VSD Screw Type Compressor

Screw75VSD

Oil-filled screw compressors are used extensively in industry, and are favoured for their large capacity, relatively quiet operation and flexibility. The latest innovation with these machines, besides the technical aspects of air-end design, is the use of variable speed drives to modulate compressor speed and hence capacity.

More details

AFLATEK Screw Compressor, High Efficiency Compressor, Screw Type Air Compressor, Industrial Screw Compressor, 75VSD Compressor, AFLATEK Industrial Equipment, Air Compressor 75VSD

12 342,00 € tax incl.

Ask about product
AFLATEK Screw75VSD Screw Type Compressor

AFLATEK Screw75VSD Screw Type Compressor

Oil-filled screw compressors are used extensively in industry, and are favoured for their large capacity, relatively quiet operation and flexibility. The latest innovation with these machines, besides the technical aspects of air-end design, is the use of variable speed drives to modulate compressor speed and hence capacity.



More info

It is tempting, particularly when making machine replacements, to buy the newest technology available.Running a screw  compressor unloaded for extended periods of time is therefore inefficient, since energy is being consumed with no benefit in terms of compressed air production.

In addition to potential energy savings, there are further benefits to VSD compressors. They can generally be operated with smaller air receivers - many sites where no receiver is used at all.
A VSD compressor is a smart choice when demand for air varies by process, time of day, shift or time of the year. When demand fluctuates, a VSD compressor that varies its speed is much more energy efficient than a fixed-speed compressor that can only run flat out.

Technical information:

DescriptionsScrew75VSD
Capacity 7.5 m3/min
Presure 1.0MPa
Power 55 Kw
Voltage 380V
Weight 1000Kg
Dimensions 1900x1250x1610mm

OIL AIR SEPARATOR
Design Presure 1,58 Mpa
Volume 100 L
Max working presure 1,5 Mpa
Design temp. 150oC
Testing Presure 2,37 MPa
