RESPO 750M301L150 PLH Single Axle Cargo Trailer 3.00x1.50m

 750M301L150 PLH High-Performance Cargo Trailer

The 750M301L150 PLH is a high-quality, innovative trailer designed for rigorous professional and domestic use. It features monolithic bent side panels and is assembled using ultra-durable HuckLok® rivet connections, ensuring structural integrity under load. The trailer is constructed from sheet metal treated with a Magnelis® coating, which is scientifically proven to be three times more resistant to corrosion than standard HDG (Hot-Dip Galvanised) sheet metal.

Exceptional handling and a long service life are guaranteed by the 4-leaf spring suspension system, paired with shock absorbers and waterproof wheel hubs. The cargo area features a robust floor made from waterproof, non-slip plywood, ensuring your load remains secure during transport. This model also includes a tipping function for easy unloading of bulk materials.

Key Features and Benefits

• Superior Corrosion Resistance: Manufactured with Magnelis® coating for extended durability in harsh weather conditions.
• Heavy-Duty Construction: Features HuckLok® riveting and a bolted sheet metal frame.
• Advanced Suspension: Equipped with 4-leaf springs and shock absorbers for a smooth ride.
• High Capacity Components: Although rated for 750 kg, the axle beam has a technical capacity of 1350 kg and hubs are rated for 2 x 675 kg, providing a significant safety margin.
• Versatile Loading: Includes a tipping function (with screw), removable front and rear hatches, and a reinforced rear hatch that can serve as a ramp.

Standard Equipment

This trailer comes fully equipped with the following features included in the box:

• Support wheel with clamp and solid tyre
• Waterproof front LED lights
• Removable front hatch
• Removable rear hatch
• Reinforced rear hatch with waterproof plywood
• 8 x Lashing eyes/tie-down points
• Tipping screw mechanism
• Adjustable axle position
• Full metal step on mudguards
• Side steps
• Wheels with M+S (Mud and Snow) tyres

Technical Specifications
